| Country of Origin: |
| China |
| Main Export Markets: |
|
| printing nova screen |
| Post Date :2017-01-06 |
| Expire Date :2015-08-01 |
 View Basket |
| moq: 20pcs, technical parameter: 640,820,914,1018,1168,1206,1450,1620,1680mm, use for: textile printing, model: 135(135V),165(165V),195mesh |
| Detailed Trade Lead Description |
|
Detailed Information：
|
|
Mesh Series：135(135V),165(165V),195mesh
|
|
Length Series：1450-3500mm
|
|
Repeat Series：640,820,914,1018,1168,1206,1450,1620,1680mm
|
|
Note:specific specification can be produced according to customers requirements as well as can produce in line with customers extraordinary requirements.
|
|
Characteristic: Close hole,big hole diameter,good elasticity and less blocking. can improve speed of printing , low cost, high utilization ratio,is a kind of highest quality screen available currently , will improve printing effect by upgrading process,and can save dyestuff,especially used in printing any fine pattern in printing industry.
|
目数(Mesh )
|
厚度(μm)
|
开孔率(%)
|
孔径(μm)
|
|
135
|
105
|
24
|
92
|
|
135V
|
105
|
24
|
92
|
|
135H
|
120
|
22
|
88
|
|
165
|
100
|
21
|
71
|
|
165V
|
100
|
21
|
71
|
|
165H
|
115
|
19
|
67
|
|
195
|
100
|
18
|
55
|
|
195H
|
115
|
18
|
52
|
|
|
Notes:
1. All screen with "V" the hole order is 45 angle. Especially used in printing pane and line, geometrical figure, etc.
2. All screen with "H" means extra thickness.
3. All kinds of screen can be used for 5~7 times repeatedly.
|
|
|
|
